As-Built 3D Scanning of Drop Deck Trailer
- Industry: Oil & Gas / Heavy Engineering
- Challenge: A fully equipped trailer with oil tanks, pumps and piping required an accurate as-built 3D scan within a single day before the trailer was dispatched, leaving no opportunity for rework.
- Solution: We planned and executed a complete on-site 3D scan within the available window, capturing the complex assembly accurately without delaying the client's dispatch schedule.
This case study demonstrates the application of high-accuracy as-built 3D laser scanning for a drop deck trailer carrying oil tanks, enabling the creation of precise digital representations of complex field conditions. The project focused on capturing critical structural geometry, equipment placement, and dimensional data to support engineering validation, retrofit planning, and CAD-based design workflows. By replacing conventional manual measurements with comprehensive point cloud data, the solution significantly reduced survey time, minimized measurement errors, and improved design confidence. The resulting as-built digital model provided a reliable foundation for manufacturing, modification, and future maintenance activities, enabling faster decision-making, enhanced project coordination, and reduced risk throughout the engineering and product development lifecycle.
